Computer-on-Module

All
ARM9/ARM11
A76
Cortex-A7/A8
A9/A53/A55
A17/A72

CM3566

* Processor: Rockchip RK3566 Quad-core Cortex-A55, 1.8 GHz
* NPU: 1 TOPS
* RAM: 1/2/4/8GB
* Storage: 8/16/32/64/128GB
* Pin out: 5x UART, 2x USB2.0 Host, USB3.0 Host, USB2.0 OTG, LVDS/MIPI DSI, eDP, MIPI CSI, HDMI TX, CIF, GbE, PCIe2.1, 2x SDMMC, I2C, SPI, PWM, ADC, I2S, SPDIF, VOP, GPIO, etc.
* Operating system: Android 12, Debian 11, Buildroot
* Board size: 40 x 47mm
* Package: 186-pin, 0.9mm pitch
pdf icon Certificate of conformity, Test Report
REACH.pdf
ROHS.pdf

CM3588S

* Processor: Rockchip RK3588S, 4x Cortex-A76 cores @ 2.4GHz, 4x Cortex-A55 cores @ 1.8 GHz
* NPU: 6 TOPS
* RAM: 8/16GB
* Storage: 32/64/128GB
* Pin out: 7x UART, USB3.0 Host, 2x USB2.0 Host, Type-C, MIPI CSI, MIPI DPHY, HDMI/eDP, GbE, 2x PCIe2.1, SATA3.0, SDMMC, CAN, I2C, SPI, PWM, ADC, PDM, I2S, GPIO, etc.
* Operating system: Android12
* Dimensions: 57.5 x 45mm
* Package: 196-pin, 1.0mm pitch

CM3588

* Processor: Rockchip RK3588 octa-core processor, 4x Cortex-A76 cores @ 2.4GHz, 4x Cortex-A55 cores @ 1.8 GHz
* NPU: 6 TOPS
* RAM: 8/16GB LPDDR4X
* Storage: 32/64/128GB
* Pin out: 5x UART, USB3.0 HOST, 2x USB2.0 HOST, 2x Type-C, 2x MIPI CSI, MIPI DSI, MIPI DPHY, 2x HDMI TX, HDMI RX, DP, GbE, PCIe3.0/2.1, SATA, SDMMC, SDIO, PWM, SPI, CAN, SPDIF, ADC, I2C, I2S, PDM, GPIO, etc.
* Operating system: Android 12, Debian 11, buildroot
* Board size: 67 x 53mm
* Package: 230-pin, 1.0mm pitch, and 39pin FPC connector for Camera

MINI3568

* Processor: Rockchip RK3568 Quad-core Cortex-A55, 2.0GHz
* NPU: 1 TOPS
* RAM: 2/4/8GB
* Storage: 8/16/32/64/128GB
* Pin out: 6x UART, USB2.0 OTG, USB3.0 Host, USB2.0 Host, HDMI, eDP, 2x MIPI DSI (or 1x MPI DSI, 1x LVDS), MIPI CSI, 2x GbE, PCIe3.0, PCIe2.1, 2x SATA3.0, SDMMC, CAN, I2C, ADC, GPIO, PWM, SPDIF, SPI, I2S, PDM, etc.
* Operating system: Debian 11
* Board size: 70 x 58mm
* Connectors: 1.27mm pitch, 100-/30-pin Female Pin Header

CM3568

* Processor: Rockchip RK3568 Quad-core Cortex-A55, 2.0GHz
* NPU: 1 TOPS
* RAM: 1/2/4/8GB LPDDR4
* Storage: 8/16/32/64/128GB
* Pin out: 4x UART, USB3.0 Host, 2x USB2.0 Host, USB2.0 OTG, USB3.0 OTG/SATA3.0, PCIe2.1, HDMI TX, eDP, RGB, MIPI DSI, LVDS, MIPI CSI, GbE, 2x SDMMC, Audio I/O, ADC, I2C, I2S, PDM, PWM, GPIO, etc.
* Operating system: Android 12, Debian 11, Buildroot
* Board size: 60 x 45mm
* Package: 202-pin, 1.0mm pitch

PICO3566

* Processor: Rockchip RK3566 Quad-core Cortex-A55, 1.8 GHz
* NPU: 1 TOPS
* RAM: 2/4/8GB
* Storage: 8/16/32/64/128GB
* Pin out: 5x UART, USB2.0 Host, USB3.0 Host, USB2.0 OTG, 2x MIPI DSI (or 1x MIPI DSI, 1x LVDS), MIPI CSI, HDMI TX, GbE, 2x SDMMC, I2C, SPI, PWM, ADC, I2S, GPIO, etc.
* Operating system: Android12, Debian11
* Board size: 67.6 x 32mm
* Connector: 200-pin SODIMM edge connector

MINI507

* Processor: Allwinner T507-H with a quad-core Arm Cortex-A53 processor @ 1.5GHz
* RAM: 2GB/4GB
* Storage: 8GB/16GB/32GB/64GB
* Pin out: 33x UART, 3x USB2.0 Host, USB2.0 OTG, MIPI CSI, LVDS/RGB, HDMI TX, TV out, GbE, SDMMC, SDIO, SPDIF, Line out, ADC, I2S, IR, SPI, TWI, GPIO, etc.
* Operating system: Android10, Linux4.9.170
* Board size: 65mm x 51mm
* Connectors: 0.4mm pitch, 2x 100pins Board-to-Board Connectors (Plug)

CM3326S

* Processor: Rockchip RK3326-S Quad-core Cortex-A35@1.5GHz
* RAM: 1GB/2GB/4GB
* Storage: 8/16/32/64/128GB
* Pin out: 2x UART, USB OTG, LVDS/MIPI DSI/RGB, MIPI CSI, CIF, SDMMC, SDIO, Audio I/O, I2C, I2S, ADC, SPI, PWM, GPIO, etc.
* Operating system: Android 12, Debian11, Buildroot
* Board size: 37 x 45mm
* Package: 156-pin, 1.0mm pitch

CM1126

* Processor: Rockchip RV1126 Quad-core Cortex-A7 @ 1.5GHz +RISC-V MCU @ 400 MHz
* NPU: 2 TOPS
* RAM: 2GB/4GB LPDDR4
* Storage: 8/16/32/64/128GB
* Pin out: 2x UART, USB2.0 HOST, USB2.0 OTG, 2x MIPI CSI, MIPI DSI, RGB, GbE, SDMMC, SDIO, CAN, SPI, ADC, I2S, PDM, I2C, PWM, GPIO, etc.
* Operating system: Buildroot
* Board size: 35.0mm x 34.0mm
* Package: 144-pin, 0.9mm pitch

MINI1126

* Processor: Rockchip RV1126 Quad-core Cortex-A7 @ 1.5GHz +RISC-V MCU @ 400 MHz
* NPU: 2 TOPS
* RAM: 2GB/4GB LPDDR4
* Storage: 8/16/32/64/128GB
* Pin out: 3x UART, USB2.0 Host, USB2.0 OTG, RGB, MIPI DSI, 2x MIPI CSI, GbE, SDMMC, SDIO, Audio I/O, I2C, SPI, ADC, PDM, CAN, GPIO, etc.
* Operating system: Buildroot
* Board size: 38.0mm x 30.0mm
* Connectors: 0.5mm pitch, 2 x 80pins Female Connectors

PICO-IMX8M-MINI

* Processor: NXP i.MX8M Mini, 4x Cortex-A53 core @1.8GHz, 1x Cortex-M4F
* RAM: 1/2/4GB LPDDR4
* Storage: 8/16/32/64/128GB eMMC
* Pin out: 4x UART, USB Host, 2x USB2.0 OTG, MIPI CSI, MIPI DSI, GbE, PCIe2.1, SD, JTAG, I2C, SPI, SPDIF, SAI, GPIO, etc.
* Operating system: Linux4.14
* Board size: 67.6mm x 34.3 mm
* Connectors: 200-pin SO-DIMM edge connector

CM-A40i

* Processor: Allwinner A40i Quad-core ARM Cortex-A7 MPCore Processor @1.2 GHz
* RAM: 512MB/1GB/2GB DDR3/DDR3L
* Storage: 8/16/32GB
* Pin out: 6x UART, 2x USB2.0 Host, USB2.0 OTG, LVDS/RGB, MIPI DSI, HDMI TX, MIPI CSI, GbE, SATA, 2x SDMMC, TV IN, SPDIF, Audio I/O, SPI, I2S, PWM, ADC, TWI, IR, Keypad, GPIO, etc.
* Operating system: Linux3.10, Android7.1.1
* Board size: 58mm x 45mm
* Package: 196-pin, 1.0mm pitch

CM-MT6737

* Processor: MediaTek MT6737 quad core Cortex A53 processor @ 1.3 GHz with Mali-T720MP GPU
* RAM: 1GB/2GB
* Storage: 4/8/16/32GB
* Pin out: 4x UART, USB2.0 Host, MIPI DSI, 2x MIPI CSI, SD, SIM, Audio I/O, SPI, I2C, I2S, GPIO, etc.
* Operating system: Android7.0
* Board size: 60mm x 38mm x 2.2mm
* Package: 150-pin, 1.27mm pitch

MINI3399

* Processor: Rockchip RK3399, Dual-core Cortex-A72 @1.8GHz + Quad-core Cortex-A53 @1.4GHz
* RAM: 4GB
* Storage: 8GB
* Pin out: 5x UART, 2x USB2.0 Host, 2x Type-C, HDMI TX, eDP, LVDS/MIPI TX, MIPI TX/RX, MIPI RX, CIF, GbE, PCIe2.1, SDMMC, SDIO, PWM, ADC, SPDIF, I2S, SPI, GPIO, etc.
* Operating system: Android11
* Board size: 82 x 58mm
* Connectors: 1.27mm pitch, 100-/40-pin Female Pin Header

CM3399

* Processor: Rockchip RK3399, Dual-core Cortex-A72 @1.8GHz + Quad-core Cortex-A53 @1.4GHz
* RAM: 1/2/4GB LPDDR4
* Storage: 8/16/32/64/128GB
* Pin out: 2x UART, 2x USB2.0 Host, 2x Type-C, MIPI TX/RX, MIPI TX, MIPI RX, HDMI TX, eDP, GbE, PCIe2.1, SDIO, SDMMC, SPI, I2C, I2S, PWM, ADC, GPIO, etc.
* Operating system: Android 7.1.2, Debian 10, buildroot
* Board size: 55mm x 50mm
* Package: 202-pin, 1.0mm pitch
pdf icon Certificate of conformity, Test Report

PICO3399

* Processor: Rockchip RK3399, Dual 64-bit Cortex-A72 + Quad Cortex-A53 @ 1.8GHz
* RAM: 1/2/4GB LPDDR4
* Storage: 8/16/32/64/128GB
* Pin out: 2x UART, 2x USB2.0 Host, 2x Type-C, MIPI TX, MIPI TX/TX, MIPI RX, HDMI TX, eDP, CIF, GbE, PCIe2.1, SDMMC, SDIO, I2C, I2S, ADC, SPI, SPDIF, GPIO, etc.
* Operating system: Android 11, Debian 10, Ubuntu 16.04
* Board size: 50mm x 82mm
* Connectors: MXM3.0-314P card edge connector
CE Certification, CE-EMC Report
FCC Certification, FCC-VOC Report

CM3288

* Processor: Rockchip RK3288 quad core ARM Cortex A17 processor @ 1.8 GHz
* RAM: 1GB/2GB LPDDR3
* Storage: 4/8/16/32GB
* Pin out: 5x UART, 2x USB2.0 Host, USB2.0 OTG, RGB/LVDS, MIPI RX, MIPI TX, MIPI TX/RX, eDP, HDMI TX, CIF, GbE, SDIO, SDMMC, SPI, I2C, I2S, PWM, ADC, SPDIF, GPIO, etc.
* Operating system: Android 9, Android7.1.2, Ubuntu16.04
* Board size: 46mm x 60mm
* Package: 204-pin, 1.0mm pitch

MINI3288

* Processor: Rockchip RK3288, Quad Core Cortex-A17 @1.8GHz
* RAM: 512MB/1GB/2GB DDR3L
* Storage:4/8/16/32GB eMMC
* Pin out: 5x UART, 2x USB2.0 Host, USB2.0. OTG, LVDS/RGB, MIPI TX/RX, HDMI TX, CIF, GbE, SDMMC, SDIO, SPI, I2C, I2S, ADC, PWM, PS2, SPDIF, GPIO, etc.
* Operating system: Android 9, Android 7.1, Ubuntu 16.04
* Board size: 70mm x 58mm
* Connectors: 1.27mm pitch, 2x50pins Female Pin Header
CE Certification, CE-EMC Report
FCC Certification, FCC-VOC Report

CMH6

* Processor: Allwinner H6 Quad-core 64-bit ARM Cortex A53
* RAM: 1GB/2GB LPDDR3
* Storage: 4/8/16/32/64/128GB
* Pin out: 3x UART, USB3.0 Host, USB2.0 Host, USB2.0 OTG, HDMI TX, RGB/CSI/GMAC, CVBS, Ethernet, PCIe, SDIO, SDMMC, MIC, SPDIF, Line out, I2C, SPI, ADC, PWM, IR, GPIO, etc.
* Operating system: Android7.0
* Board size: 45mm x 45mm
* Package: 138-pin, 1.25mm pitch

MINI3188

* Processor: Rockchip RK3188, Quad-Core ARM Cortex-A9 @ 1.6GHz
* RAM: 512MB/1GB DDR3
* Storage: 4/8/16/32GB
* Pin out: 3x UART, USB2.0 Host, USB2.0 OTG, 2x RGB LCD, Ethernet, CIF, SDMMC, SPI, ADC, I2C, I2S, PWM, SPDIF, GPIO, etc.
* Operating system: Android5.1
* Board size: 67.0mm x 51.0mm
* Connectors: 1.0mm pitch, 2x50pins Header

MINI4418

* Processor: Samsung S5P4418, Cortex-A9 Quad-Core, 1.4GHz
* RAM: 512MB/1GB DDR3
* Storage: 4/8/16/32GB eMMC
* Pin out: 5x UART, USB2.0 Host, USB2.0 OTG, HDMI, RGB, LVDS/MIPI DSI, CIF, CVBS, GbE, 2x SDMMC, I2S, ADC, PWM, I2C, SPI, JTAG, IR, SPDIF, GPIO, etc.
* Operating system: Android4.4.2
* Board size: 70mm x 58mm
* Connectors: 1.27mm pitch, 2x50pins Female Pin Header

MINI4412

* Processor: Samsung Exynos 4412, Cortex A9 Quad Core @1.6GHz
* RAM: 1GB/2GB DDR3
* Storage: 4/8/16/32GB eMMC
* Pin out: 4x UART, USB2.0 Host, USB2.0 OTG, RGB, HDMI, MIPI DSI, 2x MIP Camera, CVBS, Ethernet, 2x SDMMC, SPDIF, I2C, ADC, SPI, PWM, I2S, Keypad, GPIO, etc.
* Operating system: Linux3.5, Android4.0/4.2.2/4.4.4
* Board size: 65mm x 47mm
* Connectors: 1.0mm pitch, (2x20+2x27)pins Pin Header

CM3128

* Processor: Rockchip RK3128, Quad Core Cortex-A7 @1.2GHz
* RAM: 512MB/1GB DDR3
* Storage: 4/8/16/32GB eMMC
* Pin out: 3x UART, USB2.0 Host, USB2.0 OTG, LVDS/MIPI DSI, HDMI TX, CIF, CVBS, Ethernet, 2x SDMMC, SPDIF TX, Audio I/O, SPI, I2C, I2S, ADC IN, PWM, GPIO, IR, GPIO, etc.
* Operating system: Android 7.1
* Board size: 55 x 45mm
* Package: 148-pin, 1.3mm pitch

CMIMX7

* Processor: NXP i.MX7Dual ARM Cortex-A7 processor @ 1.2 GHz, with Cortex-M4 @ 200 MHz
* RAM: 512MB/1GB DDR3
* Storage: 4/8/16/32GB eMMC
* Pin out: 5x UART, 2x USB2.0 OTG, EPD, LCD, MIPI DSI, MIPI CSI, GbE, SD, PCIe, 2x CAN, Audio out, I2C, ADC, SPI, SAI, PWM, GPIO, etc.
* Operating system: Android6.0.1, Linux+QT
* Board size: 67.6mm x 37.0mm
* Connectors: SODIMM200 card edge connector(2.5V)

CM6ULL

* Processor: NXP i.MX 6ULL ARM Cortex-A7™ @ 528MHz
* RAM: 256/512MB DDR3L
* Storage: 4/8/16/32GB eMMC
* Pin out: 5x UART, 2x USB OTG, RGB, Parallel CSI, 2x Ethernet, SD, SPDIF, SAI2, PWM, GPIO, etc.
* Operating system: Linux4.1.15
* Board size: 67.7mm x 30.0mm
* Connectors: SODIMM200 card edge connector

CM210-II

* Processor: Samsung ARM Cortex-A8 S5PV210AH @1GHz
* RAM: 256/512MB DDR2
* Storage: 256MB/512MB/1GB
* Pin out: 4x UART, USB2.0 Host, USB2.0 OTG, RGB, HDMI, Camera I/F, 2x SDMMC, GPIO, I2S, I2C, SPI, etc.
* Operating system: Android4.0
* Board size: 65.5mm x 53mm
* Package: 140-pin, 1.27mm pitch

CM210-III

* Processor: Samsung ARM Cortex-A8 S5PV210AH @1GHz
* RAM: 256/512MB
* Storage: 512MB/1GB/2GB/4GB/8GB/32GB
* Pin out: 4x UART, USB2.0 Host, USB2.0 OTG, RGB, HDMI, Camera I/F, TV out, Ethernet, 2x SDMMC, SPI, I2C, Audio I/O, JTAG, ADC, Keypad, PWM, GPIO, etc.
* Operating system: Linux2.6.32, WinCE6.0(R3), Android4.0
* Board size: 59.9mm x 61.55mm
* Package: 230-pin, 1.0mm pitch

MINI210-III

* Processor: Samsung ARM Cortex-A8 S5PV210 @ 1GHz
* RAM: 256MB DDR2
* Storageh: 256MB/512MB/1GB/2GB
* Pin out: 4x UART, USB2.0 Host, USB2.0 OTG, RGB, 2x Camera I/F, TV out, 2x SDMMC, JTAG, I2C, ADC, PWM, I2S, SPI, GPIO, etc.
* Operating system: Linux3.0.8
* Board size: 37mm x 74mm
* Compatible module: MINI2416-III, MINI2440
* Connectors: 2.0mm pitch, (2x12+2x36)pins Pin Header

MINI6410

* Processor: Samsung S3C6410, ARM1176JZF-S @667MHz
* RAM:128/256MB
* Storage: 256MB/512MB/1GB
* Pin out: 4x UART, USB1.1 Host, USB2.0 OTG, RGB, Camera I/F, TV out, 2x SDMMC, I2C, Keypad, ADC, SPI, PWM, GPIO, etc.
* Operating system: Linux2.6.28, WinCE6.0, Android2.3
* Board size: 52mm x 45mm
* Package: 184-pin, 1.0mm pitch

CM9X35

* Processor: Atmel AT91SAM9X35 @ 400 MHz
* RAM: 64/128MB DDR2
* Storage: 256MB/512MB/1GB
* Pin out: 5x UART, 3x USB2.0 Hos, LCD, Ethernet, 2x SDMMC, Audio I/O, I2C, SPI, PWM, GPIO, etc.
* Operating system: Linux2.6.39
* Board size: 40mm x 40mm
* Compatible module: MINI2416, MINI287
* Package: 120-pin, 1.27mm pitch

MINI287

* Processor: Freescale i.MX287 ARM926EJ-S CPU @ 454 MHz
* RAM: 64/128MB DDR2
* Storage: 256MB/512MB/1GB
* Pin out: 5x UART, USB2.0 OTG, USB2.0 Host, LCD, 2x Ethernet, CAN, Audio I/O, 2x SD, SPI, GPMI, PWM, I2C, ADC, GPIO, etc.
* Operating system: Linux2.6.39
* Board size: 40mm x 40mm
* Compatible module: CM9X35, MINI2416
* Package: 120-pin, 1.27mm pitch

MINI9G25

* Processor: Atmel AT91SAM9G25, ARM9 @400Mhz
* RAM: 64/128MB DDR2
* Storage: 128/256/512MB
* Pin out: 7x UART, 2x USB2.0 Host, USB2.0 OTG, Ethernet, SD, I2C, SPI, GPIO, ADC, PWM, etc.
* Operating system: Linux
* Board size: 40mm x 40mm
* Package: 96-pin, 1.27mm pitch

MINI2416

* Processor: Samsung ARM9 S3C2416X @400MHz
* RAM: 64MB
* Storage: 128MB/256MB/512MB/1GB optional
* Pin out: 4x UART, USB1.1 Host, USB2.0 Device, RGB, Ethernet, 2x SDMMC, Audio I/O, PWM, I2C, SPI, ADC, GPIO, etc.
* Operating system: Linux2.6, WinCE6.0
* Board size: 40mm x 40mm
* Compatible module: CM9X35, MINI287
* Package: 120-pin, 1.27mm pitch

MINI2416-III

* Processor: Samsung ARM9 S3C2416X @400MHz
* RAM: 64/128MB DDR2
* Storage: 128MB/256MB/512MB/1GB optional
* Pin out: 4x UART, USB1.1 Host, USB2.0 Device, RGB, 2x SDMMC, I2S, I2C, SPI, PWM, ADC, GPIO, etc.
* Operating system: Linux2.6.21, WinCE6.0
* Board size: 74mm x 37mm
* Compatible module: MINI2440, MINI210-III
* Connectors: 2.0mm pitch, (2x12+2x36)pins Pin Header
* RoHS Certification
* CE Certification, EMC Report

MINI2440

* Processor: Samsung ARM9 S3C2440A ARM920T @400MHz
* RAM: 64/128MB SDRAM
* NOR Flash: 2MB
* Storage: 128/256/512MB/1GB
* Pin out: 3x UART, 2x USB1.1 Host, RGB, Camera I/F, SD, ADC, SPI, JTAG, I2S, I2C, GPIO, etc.
* Operating system: Linux 2.6.25/30, Windows CE6.0
* Board size: 37mmx 74mm
* Compatible module: MINI2416-III, MINI210-III
* Connectors: 2.0mm pitch, (2x12+2x36)pins Pin Header
